    330 4" Union black FF

    Fitting of malleable cast iron B300-06. Fittings are specified for joining of threaded according to ISO 7-1. Design is black.

    Your price1 814,27 Kč
    Your price without VAT1 499,40  Kč
    In stock (15 pcs)Not in stock
    Unit:pcs
    Code 2:012.FC.330.100
    EAN:
    8592018409286
    Warranty:2 YEARS
    Norms: ČSN EN 10242, ČSN ISO 7-1
    Certificates: B-31-00636-04

    Description

    Thread pipe fitting from malleable cast iron, kind – direct union with flat seat with inner x inner tubular threads, black design. Connecting inner threads Rc is conical for sealing of joints on the threads according of norm ISO 7-1, fixative thread of nut G is cylindrical for loose of joints on threads according of norm ISO 228-1. It consist of three parts: 370 ( direct socket ) + 374 ( cap nut ) + 372 ( supporting socket with inner thread ). Produced according of norm EN 10242, mark U1. Attention: union should use like built-up of complex only, because individual parts of the union with different production marks or individual parts of different types and same production marks can’t be compatible! Using: Intended for distribution of water, air, gas, nonabrassive and nonaggressive fluid to allowed press 25 bar and temperature from -20 to 120°C, with necessity of prevention for freezing of media.

    Technical specification

    Parametry pro vyhledávače

    Hmotnost
    Hmotnost
    3

    330 4" Union galv.

    FP3304
    2 031,95  Kč / pcs with VAT
    In stock (29 pcs)Not in stock
    Fitting of malleable cast iron B300-06. Fittings are specified for joining of threaded according to ISO 7-1. Design: galvanized. Zinc coating thickness of 70 microns is generated by hot dip galvanizing
